DH-IPC-HFW1439S1P-A-LED-0360B-S4

4 MP Entry Full-color Fixed-focal Bullet Network Camera

> 4-MP 1/3" CMOS image sensor, low luminance, and high definition image

> H.265 codec, high compression rate, ultra-low bit rate

> Outputs max. 4 MP (2560 × 1440)@25/30 fps

> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Abnormality detection: Motion detection, video tampering, network disconnection, IP conflict, illegal access

> Built-in warm light, and the max. illumination distance is 15 m.

> 12V DC/PoE power support

> IP67

This combination does not exist.

Terms and Conditions

Shipping: 2-3 Business Days

Technical Speciﬁcation
Camera
Image Sensor	1/3” 2Megapixel progresive CMOS
Effective Pixels	2560(H) x1440(V)
RAM/ROM	128MB/128MB
Scanning System	Progressive
Electronic Shutter Speed	Auto/Manual, 1/3~1/100000s
Minimum Illumination	0.008 lux@F1.6
S/N Ratio	>56dB
IR Distance	15 m (49.21 ft) (Warm light)
IR On/Off Control	Auto/ Manual
IR LEDs	1 (Warm light)
Lens
Lens Type	Fixed
Mount Type	M12
Focal Length	2.8 mm 3.6 mm
Max. Aperture	F1.6
Angle of View	H: 95°; V: 52°; D: 114°; H: 78°; V: 41°; D: 94°
Focus Control	Fixed
Close Focus Distance	0.9 m (2.95 ft); 1.6 m (5.25 ft)
DORI Distance	Lens	Detect	Observe	Recognize	Identify
2.8 mm	63.6 m (208.66 ft)	25.4 m (83.33 ft)	12.7 m (41.67 ft)	6.4 m (20.9 ft)
3.6 mm	85.4 m (280.18 ft)	34.2 m (112.20 ft)	17.1 m (56.1 ft)	8.5 m (27.89ft)
PTZ
Pan/Tilt Range	Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°
Video
Compression	H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)
Streaming Capability	2 Streams
Resolution	4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Frame Rate	Main stream: 2560 × 1440@ (1–25/30 fps)
sub stream: 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
Bit Rate Control	CBR/VBR
Bit Rate	H.264: 32 kbps–6144 kbps H.265: 12 kbps–6144 kbps
Day/Night	Color/B/W
BLC Mode	BLC / HLC /WDR (120 db)

White Balance	Auto/Natural/Street Lamp/Outdoor/Manual/regional custom
Gain Control	Auto/Manual
Noise Reduction	3D DNR
Motion Detection	Off / On (4 Zone, Rectangle)
Region of Interest	Yes (4 areas)
Smart IR	Support
Digital Zoom	16x
Flip	0°/90°/180°/270° (Support 90°/270° with 2560 × 1440 resolution and lower)
Mirror	Off / On
Privacy Masking	Off / On (4 Area, Rectangle)
Alarm
Alarm Event	Network disconnection; IP conflict; illegal access; motion detection; video tampering; voltage detection; security exception
Network
Ethernet	RJ-45 (10/100Base-T)
Protocol	IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
Interoperability	ONVIF (Profile S/Profile T); CGI; P2P; Milestone
Streaming Method	Unicast / Multicast
Max. User Access	20 (Total bandwidth: 48 M)
Edge Storage	FTP; SFTP; NAS
Web Viewer	IE, Chrome, Firefox
Management Software	Smart PSS, DSS, DMSS
Smart Phone	IOS, Android
Certifications
Certifications	CE-LVD: EN 62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B
Interface
Video Interface	N/A
Audio Interface	N/A
RS485	N/A
Alarm	N/A
Electrical
Power Supply	DC12V PoE (802.3af)
Power Consumption	Basic: 2.1 W (12 VDC); 3 W (PoE) Max. (WDR+H.265+ warm light intensity): 4.3 W (12 VDC); 5.3 W (PoE)
